Pocket-sized bug detector, 4G network transmissions and radio transmitters

User Friendly
Scan from 40 to 3800MHz
Monitoring with reports
Identification of modulation
Adaptive scanning and search

prod cod: RIL-RF-DIR-LTE

Free customer service:

📞 Pre-Sale assistance

🧑‍💼 Dedicated consultation service

🛠️ After-Sales 🎓 Training and Support

🆘 Technical and operational support

Portable RF Bug and Microtransmitter Detector

The RIL-RF-DIR-LTE digital directional bug detector is an advanced tool designed for detecting and locating a wide range of radio transmitters, including covert listening devices, GSM bugs, hidden cameras, and wireless surveillance equipment. It is particularly useful for preventing unauthorized access to sensitive data and confidential information. Additionally, it serves as an effective GPS tracker detector, making it ideal for vehicle bug sweeps. Thanks to its user-friendly operation, even individuals with no prior experience in the field can use it with ease.

This device is a superheterodyne receiver with a frequency synthesizer, continuously scanning frequencies within its range (40 MHz to 3.8 GHz) while analyzing spectrogram peaks. Digital signals are identified based on their amplitude and frequency modulation characteristics. The scanning and analysis cycle occurs every 1.0–1.5 seconds.

The detector is capable of performing control, scanning, searching, and monitoring operations for both analog and digital signals, detecting the following types of devices:

Mobile phones operating on GSM (2G), UMTS (3G), and LTE (4G) networks
DECT cordless phones
Bluetooth and Wi-Fi devices
Wireless video cameras
Analog-modulated radio transmitters (AM, FM, PM)
Digitally modulated radio transmitters with continuous carrier signals (FSK, PSK, etc.)
Wideband radio transmitters with a bandwidth of up to 10 MHz

Key Features:

Selective radio signal reception
High-speed scanning and analysis
Detection of digital and wideband signals
Background noise reduction
Adjustable search modes
Audio monitoring via built-in speaker
Signal frequency and level measurement
Detection alarm
Silent alert mode (vibration)
No external antenna required

This device provides reliable protection against unauthorized surveillance equipment, ensuring accurate and efficient monitoring in sensitive environments.

Frequency Range:40 - 3800 МHz

Mobile phones and Wireless Signals:GSM 850, 900, 1800, 1900
UMTS 850, 900, 1700, 1900, 2100
LTE 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 17, 18, 19, 20, 25, 26, 28, 30, 31, 34, 38, 39, 40, 41, 42, 43, 48, 53, 66, 71

Wi-Fi, Bluetooth, DECT Signals:Yes

Typical Sensitivity:70 mV/m

Dynamic Range:50 dB

Bandwidth:10 МHz

Scan Time:≤ 4 s

Time in Monitoring Mode:5 - 14 h

Running Time in Other Modes:3 h

Maximum Number of Registrations:200

Operating Temperature:+5 - +45 °C

Dimensions:77 х 43 х 18 mm

Weight: < 50 g

Detection of bugs or radio transmission equipment in general, with the possibility of identifying the type of signal beyond the frequency (e.g. UMTS, GSM, CDMA etc.)
For bug sweeping operations carried out by sector specialists as well as for private home made remediation
